Window Framework for UI Toolkit v2.0.x
|
InventoryWindowExample is a class that represents a scrollable inventory window. It demonstrates the use of a ScrollView to display a list of simulated inventory slots. This window is designed to showcase the flexibility of the Window Framework. More...


Public Member Functions | |
| InventoryWindowExample () | |
| Constructor for the InventoryWindowExample. Initializes the window content and layout properties. | |
| Public Member Functions inherited from GWG.WindowFramework.WindowFrame | |
| WindowFrame () | |
| Represents a custom UI element serving as a container for window-based content, including a header, content, and footer, providing event handling and theme adaptability for Unity's UI Toolkit. | |
| void | CloseWindow (bool forceAll=false) |
| Closes the window if allowed. | |
| void | DockTab (WindowFrame incoming) |
| Docks an incoming standalone WindowFrame into this window as a nested tab. | |
| void | DockTo (WindowDockState targetState) |
| Applies the specified programmatic dock geometry, preserving initial floating bounds. | |
| void | ExitFullscreenToCursor (Vector2 cursorPos) |
| Exits fullscreen mode and pre-positions the restored floating window centered horizontally under the cursor. | |
| void | Hide () |
| Hides the window while keeping it in memory. | |
| void | SetOpeningPosition () |
| Sets the opening position of the window based on the selected position. Options include: TopLeft, Top, TopRight, Left, Center, Right, BottomLeft, Bottom, BottomRight. | |
| void | Show () |
| Shows the window by setting its display style to flex and opacity to 1.0f. | |
| void | SwitchToTab (int index) |
| Switches the active view to display the specified nested tab's content. | |
| void | Undock (Vector2? cursorPos=null) |
| Undocks the window frame, restoring its pre-dock floating size and positioning. | |
| WindowFrame | UndockTab (int index, Vector2? mousePos=null) |
| Undocks a nested tab back into an independent standalone WindowFrame. | |
Additional Inherited Members | |
| Properties inherited from GWG.WindowFramework.WindowFrame | |
| bool | Active [get, set] |
| Gets or sets whether the window is active. | |
| int | ActiveTabIndex [get] |
| Gets the current tab-selection index; interpret against the current live tab list. | |
| bool | AllowClose = true [get, set] |
| Gets or sets whether the window can be closed. | |
| bool | AllowFullscreen = true [get, set] |
| Determines whether the window frame can toggle to fullscreen mode. | |
| bool | AllowLock [get, set] |
| Gets or sets whether the window can be locked. | |
| bool | AllowMove = true [get, set] |
| Gets or sets whether the window can be moved. | |
| bool | AllowMultipleInstances = true [get, set] |
| Gets or sets whether multiple instances of this window are allowed. | |
| bool | AllowResize [get, set] |
| Gets or sets whether the window can be resized. | |
| bool | AllowTabDocking = true [get, set] |
| Gets or sets whether this window can participate in tabbed window nesting and docking. | |
| VisualElement | Content [get, set] |
| Gets or sets the content area of the window. | |
| override VisualElement | contentContainer [get] |
| Overrides the contentContainer to return the window's content area instead of the root. | |
| ContextMenuConfig | ContextMenuConfig [get, set] |
| Gets or sets the context menu configuration for this window. | |
| float | DefaultHeight [get, set] |
| float | DefaultWidth [get, set] |
| WindowDockState | DockState [get, set] |
| Gets/sets docking metadata; assignment alone does not reposition or resize this window. | |
| WindowFrameDragger | Dragger [get] |
| Gets the installed header dragger, which can be null before scheduled setup. | |
| VisualElement | FooterToolbar [get, set] |
| Gets or sets the toolbar in the footer area of the window. | |
| bool | Fullscreen [get, set] |
| Gets or sets whether the window is in fullscreen mode. | |
| bool | Locked [get, set] |
| Gets or sets whether the window is locked. | |
| bool | LockedFullscreen [get, set] |
| Determines whether the fullscreen mode of the window is locked, preventing the user from toggling fullscreen on or off. | |
| bool | LockedToStartPosition [get, set] |
| Gets or sets whether the window is locked to its start position. | |
| float | MinHeight [get, set] |
| Gets or sets the minimum height of the window. | |
| float | MinWidth [get, set] |
| Gets or sets the minimum width of the window. | |
| IReadOnlyList< WindowTabEntry > | NestedTabs [get] |
| Gets the live nested-tab list through a read-only interface, not an independent snapshot. | |
| string | OptionsMenuTooltip [get, set] |
| Gets or sets the tooltip for the options menu button. | |
| string | ParentObjectId [get, set] |
| Gets or sets the ID of the parent object associated with the window. | |
| Rect | PreDockRect [get, set] |
| Gets/sets floating restore bounds in parent layout coordinates. | |
| string | ResizeAreaTooltip [get, set] |
| Gets or sets the tooltip for the resize area. | |
| bool | ShowFooter [get, set] |
| Gets or sets whether the footer is visible. | |
| bool | ShowHeader [get, set] |
| Gets or sets whether the header is visible. | |
| WindowFramePosition | StartPosition [get, set] |
| Gets or sets the position of the window frame. | |
| List< StyleSheet > | StyleSheet [get, set] |
| Gets or sets the stylesheet applied to the window. | |
| string | Title [get, set] |
| Gets or sets the title of the window. | |
| string | WindowId [get, set] |
| Gets or sets the unique ID of the window. | |
| bool | WindowMemoryEnabled = false [get, set] |
| Gets or sets whether the window memory is enabled. | |
| Events inherited from GWG.WindowFramework.WindowFrame | |
| static Action< WindowFrame > | OnWindowFrameAdded |
| Event triggered when a new WindowFrame is added to the panel. | |
| static Action< WindowFrame > | OnWindowFrameRemoved |
| Event triggered when a WindowFrame is removed from the panel. | |
InventoryWindowExample is a class that represents a scrollable inventory window. It demonstrates the use of a ScrollView to display a list of simulated inventory slots. This window is designed to showcase the flexibility of the Window Framework.
This is a visual slot demonstrator, not an inventory data/transaction system. Its constructor generates a new GUID-suffixed WindowId each time. Although memory is enabled, that identity is not stable across reconstruction and must not be copied as a purchaser's remembered-window identity pattern. Use stable WindowId and owning ParentObjectId for production.
|
inline |
Constructor for the InventoryWindowExample. Initializes the window content and layout properties.
